Welcome to this demonstration on Bonus Tools – 132 Reload From Links. This powerful tool reloads and repaths links in bulk from an Excel file using External Resource References, enabling sophisticated link management including C4R cloud link repathing. Use in conjunction with tool 133 Export Links.

Key Features
Requirements
How It Works
Required Workflow
Excel File Format
Step-by-Step Guide
Supported Link Types
Example Workflows
Tips and Best Practices
Common Use Cases
Troubleshooting

Key Features

Bulk Link Reloading: Process multiple links simultaneously from Excel
External Resource References: Uses advanced API method for reliable repathing
C4R Cloud Support: Fully supports cloud-hosted (BIM 360/ACC) links
Multiple Link Types: Handles Revit links, CAD links, keynote tables, assembly codes
Excel-Based Control: Edit paths and settings in familiar spreadsheet format
Color-Coded Output: Real-time feedback on success/failure
Transaction Safety: Protected operations with automatic rollback on errors
Validation: Checks for required data before processing
Batch Processing: Handle hundreds of links efficiently

Requirements

Essential Components

Valid Bonus Tools License: Active license key required
Excel File from Tool 133: Must first export links using 133 Export Links
Excel Software: Microsoft Excel or compatible spreadsheet editor
Open Revit Project: Project containing links to be reloaded
Link Accessibility: New link paths must be accessible to Revit
Write Permissions: Ability to modify project links

Prerequisites

Critical Workflow:

First, run 133 Export Links to create base Excel file
Edit Excel file with new paths/information
Then run 132 Reload From Links with edited file

Cannot skip step 1 - Tool requires External Resource Reference data that only 133 Export Links can provide.

Recommended Setup

Backup Project: Save copy before bulk repathing
Test First: Try on single link before bulk operation
Verify Paths: Ensure new paths are valid and accessible
Close Dialogs: Tool will attempt to dismiss dialogs automatically
Output Window: Keep visible to monitor progress

How It Works

Processing Flow

1. File Selection

Tool prompts for Excel file (from 133 Export Links)
Opens and reads "General" worksheet
Validates required columns present

2. Data Extraction

Reads each row (skips header)
Extracts External Resource Reference data:
- Server ID (GUID)
- Reference Information dictionary
- Version information
- In-Session Path
- Display Name
- Link Type

3. Validation

Checks all required fields present
Verifies GUIDs valid
Confirms paths exist
Reports any errors to output window

4. Link Processing

For each valid entry:
- Identifies link type
- Finds matching link in project
- Creates External Resource Reference
- Reloads link from new reference
- Reports success (green) or failure (red)

5. Completion

Shows count of processed files
Displays comprehensive log
Commits changes if successful

External Resource Reference Method

Why This Method:

Standard path repathing doesn't work for C4R links
External Resource References provide API-level access
Required for cloud-hosted link management
More reliable for complex link scenarios
Supports all link types uniformly

What Gets Used:

ExternalResourceReference Components:
- ServerId: Unique GUID identifying server/source
- ReferenceInformation: Dictionary of link metadata
- Version: Version information string
- InSessionPath: New path or location for link

Required Workflow

Step-by-Step: Export, Edit, Reload

Phase 1: Export Current Links (Tool 133)

Open project with links to repath
Launch "133 Export Links"
Check desired link types
Export to Excel
Save Excel file with descriptive name

Phase 2: Edit Excel File

Open exported Excel file
Navigate to "General" worksheet
Locate "InSessionPath" column
Edit paths as needed:
- For local links: C:\NewPath\File.rvt
- For network links: \\Server\Path\File.rvt
- For C4R links: Proper cloud path format
Do NOT modify other columns:
- LinkType
- ServerId
- Version
- DisplayName
- Reference Information columns
Save Excel file

Phase 3: Reload Links (Tool 132)

Ensure project still open
Launch "132 Reload From Links"
Select edited Excel file
Monitor output window
Review results
Verify links loaded correctly

Critical Rules:

MUST use Excel from Tool 133 (contains required metadata)
ONLY edit InSessionPath column
DO NOT modify GUIDs, version info, or reference data
Maintain exact worksheet name ("General")
Keep header row intact

Excel File Format

Required Worksheet

Name: "General" (exact match required)

Required Columns

Column Headers (order can vary, but names must match exactly):

LinkType
- Value: Link type name (e.g., "RevitLink", "CADLink")
- DO NOT EDIT
- Used to determine processing method
InSessionPath
- Value: File path or location
- EDIT THIS for repathing
- New path where link should load from
- Examples:
  - C:\Projects\NewLocation\File.rvt
  - \\Server\Share\Folder\File.dwg
  - RSN://Server/Project/File.rvt (C4R)
ServerId
- Value: GUID string
- DO NOT EDIT
- Example: {12345678-1234-1234-1234-123456789012}
- Critical for External Resource Reference
Version
- Value: Version string
- DO NOT EDIT
- May be empty for some link types
- Preserved from export
DisplayName
- Value: Link name as shown in Revit
- DO NOT EDIT
- Used to match link in project
- Must remain exactly as exported
Additional Columns (Reference Information)
- Various metadata columns
- DO NOT EDIT
- Part of External Resource Reference
- Examples: ProjectId, ModelId, etc.

Example Excel Structure

LinkType    | InSessionPath           | ServerId        | Version | DisplayName
------------|-------------------------|-----------------|---------|------------------
RevitLink   | C:\Old\ARCH.rvt        | {guid}          | 15      | ARCH.rvt
RevitLink   | C:\Old\STRUCT.rvt      | {guid}          | 8       | STRUCT.rvt
CADLink     | C:\CAD\Site.dwg        | {guid}          |         | Site.dwg

After Editing (change paths only):

LinkType    | InSessionPath           | ServerId        | Version | DisplayName
------------|-------------------------|-----------------|---------|------------------
RevitLink   | C:\NEW\ARCH.rvt        | {guid}          | 15      | ARCH.rvt
RevitLink   | C:\NEW\STRUCT.rvt      | {guid}          | 8       | STRUCT.rvt
CADLink     | C:\NEW_CAD\Site.dwg    | {guid}          |         | Site.dwg

Validation Rules

Tool will reject rows with:

Empty ServerId
Invalid GUID format
Missing InSessionPath
Empty DisplayName
No Reference Information data
Missing LinkType

Rejected rows:

Logged to output window in red
Shows which field is missing
Not processed (skipped)
Does not stop other rows

Step-by-Step Guide

Basic Workflow: Simple Link Repathing

Scenario: Moving project and links to new folder

1. Export Current State

Tool 133 Export Links
├── Check: Revit Link
├── Check: CAD Link
└── Export: "Project_Links_Before.xlsx"

2. Edit Excel

Open: Project_Links_Before.xlsx
Find InSessionPath column
Change:
  C:\OldProject\Links\ARCH.rvt
To:
  C:\NewProject\Links\ARCH.rvt
(Repeat for all links)
Save As: "Project_Links_New_Paths.xlsx"

3. Reload Links

Tool 132 Reload From Links
Select: Project_Links_New_Paths.xlsx
Monitor: Output window for results

4. Verify

Manage → Manage Links
Verify: All links show new paths
Test: Open link to confirm accessibility

Advanced Workflow: C4R Migration

Scenario: Moving from local file server to BIM 360

1. Export Current Local Paths

Run 133 Export Links
Focus on Revit Links
Document all current local paths

2. Upload Models to BIM 360

Upload all link files to cloud
Note new cloud paths (RSN://)
Document project structure

3. Edit Excel with Cloud Paths

Change from:
  C:\LocalServer\Project\ARCH.rvt
To:
  RSN://ProjectServer/Project/ARCH.rvt

Use proper BIM 360/ACC path format
Maintain External Resource Reference data
Update ALL Revit links

4. Reload with New Cloud Paths

Close and reopen project if needed
Run 132 Reload From Links
Select edited Excel file
Watch for errors (cloud paths are tricky)

5. Verify Cloud Links

Check Manage Links shows cloud paths
Verify links load from cloud
Test syncing
Confirm team access

Batch Workflow: Multiple Projects

Goal: Repath links across multiple related projects

1. Create Master Link Map

For each project:
├── Export links (133)
├── Combine into master spreadsheet
├── Document all link relationships
└── Plan new path structure

2. Bulk Edit Path Mapping

In Excel:
├── Create mapping table (old → new paths)
├── Use formulas to update InSessionPath
├── Apply to all project sheets
└── Save separate file per project

3. Process Each Project

For each project:
├── Open project
├── Run 132 Reload From Links
├── Load corresponding Excel file
├── Verify results
├── Move to next project

4. Validation Pass

For each project:
├── Open and check links loaded
├── Verify no missing links
├── Document any issues
└── Reprocess failures if needed

Supported Link Types

Fully Supported (Working)

1. Revit Link ✓

Class: RevitLinkType
Most commonly used
Full C4R support
Transaction protected
Output feedback provided

2. CAD Link ✓

Class: CADLinkType
DWG, DGN, DXF files
Local and network paths
Transaction protected
Output feedback provided

3. Assembly Code Table ✓

Class: AssemblyCodeTable
Uniformat/classification codes
Reference table files
Transaction protected
Output feedback provided

4. Keynote Table ✓

Class: KeynoteTable
Keynote text files
Annotation reference
Transaction protected
Output feedback provided

Not Yet Implemented

5. Decal Bump Map ✗

Material texture maps
Code structure exists but not active
Future implementation possible

6. Decal Cut Out ✗

Material transparency maps
Code structure exists but not active
Future implementation possible

7. Decal Map ✗

Material appearance images
Code structure exists but not active
Future implementation possible

8. DWF Markup ✗

DWF markup files
Code structure exists but not active
Future implementation possible

9. IFC Link ✗

Industry Foundation Classes
Code structure exists but not active
Future implementation possible

10. Point Cloud ✗

Laser scan data (RCS, RCP)
Code structure exists but not active
Future implementation possible

11. Fabrication Configuration ✗

MEP fabrication databases
Code structure exists but not active
Future implementation possible

Note: Focus on working types (Revit, CAD, Assembly, Keynote) for production use.

Example Workflows

Workflow 1: Server Migration

Goal: Move all project links from old server to new server

Preparation:

Export all links (133)
Document current paths
Set up new server structure
Copy all link files to new location

Excel Editing:

Find and Replace:
  Find: \\OldServer\
  Replace: \\NewServer\
  In Column: InSessionPath

Before: \\OldServer\Projects\A\ARCH.rvt
After:  \\NewServer\Projects\A\ARCH.rvt

Execution:

Test with one project first
Run 132 Reload From Links
Verify links load from new server
Process remaining projects
Update central models if workshared

Verification:

All links show new server paths
Links load successfully
No "Not Found" status
Team can access new location

Workflow 2: Folder Reorganization

Goal: Reorganize project folder structure

Old Structure:

C:\Projects\
├── ARCH_Model.rvt
├── STRUCT_Model.rvt
├── MEP_Model.rvt
└── Site.dwg

New Structure:

C:\Projects\
├── Models\
│   ├── ARCH_Model.rvt
│   ├── STRUCT_Model.rvt
│   └── MEP_Model.rvt
└── CAD\
    └── Site.dwg

Steps:

Export links before move
Move files to new structure
Edit Excel paths to match new structure
Reload links with new paths
Save project

Workflow 3: Standardizing Link Locations

Goal: Enforce company standard paths across projects

Company Standard:

All links in: \\CompanyServer\BIM\[ProjectCode]\Links\

Current State:

Mixed paths:
- C:\Local\Links\...
- \\OldServer\...
- Various user drives

Process:

Copy all links to standard location
Export current link state
Update Excel with standard paths
Reload using tool 132
Verify compliance
Document in project standards

Benefits:

Consistent path structure
Easier troubleshooting
Better team coordination
Simplified backups

Workflow 4: Emergency Link Recovery

Goal: Recover after accidental link path changes

Situation:

Links accidentally repathed incorrectly
Multiple links now broken
Need to restore previous paths

Recovery:

Locate last good link export (from 133)
If none exists, recreate manually
Run 132 with last good Excel file
Verify links restored
Implement regular exports going forward

Prevention:

Export links regularly (weekly)
Archive exports with project versions
Document link changes
Test repathing on copies first

Workflow 5: Multi-Discipline Coordination Path Update

Goal: Update all discipline model links after coordination meeting

Scenario:

Coordination models moved to new location
All disciplines need updated paths
Must be done simultaneously

Coordination:

BIM Manager exports all discipline links
Documents new agreed paths
Updates master Excel with new paths
Distributes to all disciplines
Each discipline runs reload tool
Verifies in coordination meeting

Excel Template:

Discipline | Old Path              | New Path
-----------|----------------------|-------------------------
ARCH       | \\Old\ARCH.rvt      | \\Coord\ARCH.rvt
STRUCT     | \\Old\STRUCT.rvt    | \\Coord\STRUCT.rvt
MEP        | \\Old\MEP.rvt       | \\Coord\MEP.rvt

Workflow 6: Cloud Migration Testing

Goal: Test cloud migration with ability to rollback

Phase 1: Preparation

1. Export current state → "Links_Local.xlsx"
2. Upload to cloud
3. Document cloud paths
4. Create "Links_Cloud.xlsx" with cloud paths

Phase 2: Test Migration

1. Open test copy of project
2. Run 132 with "Links_Cloud.xlsx"
3. Verify cloud links load
4. Test functionality
5. Document any issues

Phase 3: Rollback Test

1. Run 132 with "Links_Local.xlsx"
2. Verify return to local paths
3. Confirm rollback capability

Phase 4: Production Migration

1. Backup everything
2. Run 132 with "Links_Cloud.xlsx"
3. Test thoroughly
4. Keep local backup for emergency rollback

Tips and Best Practices

Excel File Management

Naming Convention:

ProjectName_Links_Purpose_Date.xlsx

Examples:
- Hospital_Links_New_Server_2026-01-27.xlsx
- Office_Links_Cloud_Migration_2026-01-27.xlsx
- School_Links_Reorganize_2026-01-27.xlsx

Version Control:

Keep multiple versions:
- _Before: Original export from 133
- _Edit: Working version with changes
- _Final: Confirmed working version
- _Backup: Emergency rollback version

Documentation:

Add worksheet tabs:
- General: Required data (don't rename)
- Notes: Document changes made
- Mapping: Old → New path reference
- Issues: Problems encountered

Path Editing Best Practices

Before Editing:

Copy InSessionPath column to new column
Keep original for reference
Use Excel formulas for bulk changes
Verify paths exist before saving

Path Formats:

Local:   C:\Path\To\File.rvt
Network: \\Server\Share\Path\File.rvt
Cloud:   RSN://Server/Project/File.rvt

Bulk Editing:

Find & Replace in InSessionPath column:
=SUBSTITUTE(OriginalPath, "C:\Old\", "C:\New\")

Validation:

Check no empty paths
Verify no typos in paths
Confirm file extensions correct
Test one path manually first

Processing Best Practices

Before Running:

Backup project file
Close other applications
Ensure output window visible
Verify Excel file ready
Check new paths accessible

During Processing:

Watch output window
Note any red error messages
Don't interrupt process
Allow transactions to complete
Be patient with large link counts

After Processing:

Review output summary
Check "Completed" vs "Error" counts
Verify links in Manage Links
Test opening links
Save project if successful

Troubleshooting Strategy

If Links Don't Reload:

Check output window for specific errors
Verify Excel has "General" worksheet
Confirm all required columns present
Check GUIDs not corrupted
Verify paths are accessible
Try single link first

If Some Links Fail:

Review output for specific link errors
Check those paths manually
Verify file accessibility
Confirm permissions
Try those links individually

Emergency Rollback:

Keep original Excel export
Reload with original paths
Restores previous state
Always have this backup

Common Use Cases

Infrastructure Changes

Server Migration:

Old server to new server
Network drive changes
Server name changes
Path structure updates

Folder Reorganization:

Project restructuring
Clean up scattered links
Standardize locations
Improve organization

Cloud Adoption

Local to Cloud:

Upload to BIM 360/ACC
Repath to cloud locations
Test cloud functionality
Enable team collaboration

Cloud to Local:

Download from cloud
Repath to local drives
Offline work scenarios
Backup strategies

Standards Compliance

Path Standardization:

Enforce company standards
Consistent link locations
Easier management
Better organization

Naming Convention:

Update to standard names
Consistent structure
Improved clarity
Better documentation

Disaster Recovery

Link Recovery:

Restore broken paths
Fix accidental changes
Emergency restoration
Return to working state

Migration Rollback:

Undo cloud migration
Return to previous paths
Emergency fallback
Risk mitigation

Troubleshooting

Common Issues

Problem: "Excel file not found" or "File does not exist"

Cause: Invalid file path or file deleted
Solution:
- Verify file exists
- Check file path spelling
- Ensure file not open exclusively
- Try Browse dialog again
- Check file permissions

Problem: "Worksheet 'General' not found"

Cause: Excel file missing required worksheet or renamed
Solution:
- Verify worksheet named exactly "General"
- Check Excel file from tool 133
- Don't rename worksheet
- Re-export from 133 if needed

Problem: "No links processed" (count shows 0)

Cause: No valid rows found or validation failures
Solution:
- Check output window for red error messages
- Verify ServerId column not empty
- Confirm GUIDs are valid
- Check InSessionPath not blank
- Verify DisplayName matches project links
- Ensure all required columns present

Problem: "Some links error (red) in output"

Cause: Specific link reload failed
Solution:
- Review error message for that link
- Verify new path exists and accessible
- Check file permissions
- Confirm link type supported
- Try that link manually in Manage Links
- Check if link is corrupted

Problem: "DisplayName contains an error" (red output)

Cause: Required data missing or invalid
Solution:
- Check which field showed empty:
  - ServerId: GUID corrupted or deleted
  - InSessionPath: Path deleted or empty
  - DisplayName: Name deleted
  - ReferenceInformation: Columns deleted
- Don't delete columns from Excel
- Re-export from 133 if corrupted
- Only edit InSessionPath column

Problem: "Links show old paths after reload"

Cause: Reload failed silently or not saved
Solution:
- Check output for errors
- Verify transaction committed
- Save project after reload
- Check Manage Links for actual paths
- May need to reload links manually

Problem: "Cloud (C4R) links won't reload"

Cause: Cloud path format incorrect or connectivity issues
Solution:
- Verify exact cloud path format
- Check cloud connectivity
- Confirm BIM 360/ACC access
- Review External Resource Reference data not corrupted
- Try loading link manually first
- Contact cloud administrator

Problem: "CAD links fail to reload"

Cause: CAD file issues or path problems
Solution:
- Verify CAD file exists at new path
- Check CAD file not corrupted
- Confirm file format supported (DWG, DGN, DXF)
- Try importing CAD manually first
- Check CAD file version compatibility

Problem: "Keynote or Assembly Code table doesn't update"

Cause: File format or path issues
Solution:
- Verify text file (.txt) for keynotes
- Check assembly code file format
- Confirm path accessible
- Try loading manually in Revit first
- Check file not locked by another process

Problem: "Process hangs or very slow"

Cause: Many links, network issues, or large files
Solution:
- Be patient (normal for many links)
- Check network connectivity
- Close other applications
- Process smaller batches
- Check link file sizes

Problem: "Tool completes but links still broken"

Cause: Paths still incorrect or files missing
Solution:
- Verify new paths actually correct
- Check files exist at new locations
- Review output for which links failed
- Manually test path accessibility
- Re-edit Excel and try again

Excel File Issues

Column Problems:

Missing required columns → Re-export from 133
Renamed columns → Use exact names from export
Deleted columns → Re-export, don't delete columns
Extra spaces in headers → Remove spaces, exact match needed

Data Problems:

Corrupted GUIDs → Re-export from 133
Empty required fields → Check red output messages
Wrong data types → Don't modify non-path columns
Formula errors → Use values, not formulas in Excel

Validation Errors

Output Shows:

Red message: "[DisplayName] contains an error:"
  serverId: [value or empty]
  InSessionPath: [value or empty]
  DisplayName: [value or empty]
  Version: [value or empty]
  referenceInformationDictionary: [count]

Interpretation:

Empty ServerId → GUID deleted or corrupted
Empty InSessionPath → Path not entered
Empty DisplayName → Name deleted
Dictionary count 0 → Reference columns deleted

Fix: Re-export from 133, only edit paths

Need Help? Contact support or refer to additional Bonus Tools documentation.

Thank you for using Bonus Tools - 132 Reload From Links!

Table of Contents
